Product warranty or service will not be extended if: How this guide is organized Operation is subject to the following two conditions: How this guide is organized This manual contains the following parts: Product introduction This chapter describes the features of the P4B motherboard.

It includes brief descriptions of the special attributes of the motherboard and the new technology it supports. Optional Documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

Chapter 1 This chapter describes the features of the P4B motherboard. It includes brief explanations of the special attributes of the motherboard and the new technology it supports. Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below. ATX 12V connector When this LED is lit, there is no way you can turn on the system power even if you press the power button.

This chip performs multiple system functions that include hardware and system voltage monitoring, IRQ routing, among others. These six bit PCI 2. Chapter 2 This chapter describes the hardware setup procedures that you have to perform when installing system components.

It includes details on the switches, jumpers, and connectors on the motherboard. Motherboard installation Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. This LED remains off if you plug in a 1. Position the CPU above the socket such that its marked corner matches the base of the socket lever.

Carefully insert the CPU into the socket until it fits in place. The CPU fits only in one correct orientation. If the instructions in this section do not match the CPU documentation, follow the latter.

Position the fan with the retention mechanism on top of the heatsink. Align and snap the four hooks of the retention mechanism to the holes on each corner of the module base. Make sure that the fan and retention mechanism assembly perfectly fits the heatsink and module base, otherwise you cannot snap the hooks into the holes. Hardware monitoring errors may occur if you fail to plug this connector. Unlock a DIMM socket by pressing the retaining clips outward.

Locked Retaining Clip 2. Simultaneously press the retaining clips outward to unlock the DIMM. Support the DIMM lightly with your fingers when pressing the retaining clips. Turn on the system and change the necessary BIOS settings, if any. Assign an IRQ to the card. Refer to the tables on the next page. Install the software drivers for the expansion card.

LED is lighted, you cannot turn on the system power even if you press the power button, thus preventing permanent damage to the motherboard. Also, the CNR slot does not take up the motherboard space for one PCI slot because it is a shared slot; rather, it provides you more options. Frequencies other than the recommended CPU bus frequencies are not guaranteed to be stable. BIOS see section 4. Set to pins to use the internal speaker usually included in the chassis.

Set to pins if you connected an external speaker to the Line Out jack lime color on the rear panel. No audio standard exists for the three pick-up surfaces If the case-mounted LED does not light, try reversing the 2-pin plug. This requires an external detection mechanism such as a chassis intrusion sensor or microswitch. Do not forget to connect the fan cables to the fan connectors.

Lack of sufficient air flow within the system may damage the motherboard components. These are not jumpers! DO NOT place jumper caps on the fan connectors! These headers support the next generation USB peripherals such as high resolution cameras, scanners, and printers. Intel front panel audio cable. Refer to page for the location of the jumpers. P4B Infrared Module Connector Power supply thermal connector 2-pin TRPWR If your power supply has a thermal monitoring feature, connect its thermal sensor cable to this connector.

The LED lights up when you turn on the system power, and blinks when the system is in sleep mode. You will hear the vocal POST messages instead.

Follow the instructions in Chapter 4. This feature gives you vocal POST messages and alerts to inform you of system events and boot status. In case of a boot failure, you will hear the specific cause of the problem. Powering off the computer You must first exit the operating system and shut down the system before switching off the power.

Detailed descriptions of the BIOS parameters are also provided. In DOS mode, type A: Type a filename and the path, for example, A: BIOS revision will solve your problems. Careless updating may result to more problems with the motherboard! If this happens, call the ASUS service center for support. Because the BIOS software is constantly being updated, the following BIOS setup screens and descriptions are for reference purposes only, and may not exactly match what you see on your screen.

MAIN Use this menu to make changes to the basic system configuration. While moving around through the Setup program, note that explanations appear in the Item Specific Help window located to the right of each menu. This window displays the help text for the currently highlighted field. Main Menu When you enter the Setup program, the following screen appears. XX] Sets the system to the time that you specify usually the current time. The format is hour, minute, second.

Valid values for hour, minute and second are Hour: Before attempting to configure a hard disk drive, make sure you have the correct configuration information supplied by the drive manufacturer.

Incorrect settings may cause the system to fail to recognize the installed hard disk. Refer to the drive documentation or on the drive label for this information. Self-Monitoring, Analysis and Reporting Technology system that utilizes internal hard disk drive monitoring technology. This parameter is normally disabled because the resources used in the SMART monitoring feature may decrease system performance.

Main menu items continued This field determines whether the memory clock frequency is set to be in synchronous or asynchronous mode with respect to the system frequency. However, it is recommended that you keep the default setting [Auto] to allow the system to automatically determine the appropriate CPU core voltage. South Bridge controller to the system memory, CNR slot, and other system devices. Setting to [Hub] does not guarantee better system performance. It can greatly improve the display speed by caching the display data.

You must set this to UC uncacheable if your display card does not support this feature, otherwise the system may not boot. This field sets the address of the onboard parallel port connector. Keep the default setting [Enabled] if you want to connect USB devices. Select [Disabled] if you do not wish to use the USB feature.

Windows with the APM feature. If any of the monitored items is out of range, the following error message appears: Boot Menu Boot Sequence The Boot menu allows you to select among the four possible types of boot devices listed using the up and down arrow keys. This allows you to enable or disable the full screen logo display feature. Select this option only if you do not want to save the changes that you made to the Setup program.

If you made changes to fields other than system date, system time, and password, the BIOS asks for a confirmation before exiting. Load Setup Defaults This option allows you to load the default values for each of the parameters on the Setup menus. Select [Yes] to load default values. Chapter 5 This chapter describes the contents of the support CD that comes with the motherboard package. The contents of the support CD are subject to change at any time without notice.

Visit the ASUS website for updates. Use this program if you wish to change the default vocal POST messages.
